Adapting to the collection needs of various types of household and commercial waste such as bagged, barreled, and bulk, it supports the optional installation of multiple working devices. Depending on the work scenario, bucket flipping devices (with pneumatic sealing covers), triangular buckets, fully sealed buckets, or swing arm devices can be selected. It is compatible with various commonly used specifications of garbage bins and can efficiently complete batch garbage collection, with strong versatility. By using a hydraulic driven lifting and flipping mechanism, the garbage bin can be quickly grasped, lifted, and dumped without excessive manual intervention, greatly reducing the labor intensity of sanitation personnel. The vehicle has flexible exterior dimensions, available in two lengths of 9310mm and 9610mm, with a width of 2550mm and a height of 3600mm. The wheelbase can be selected in multiple specifications ranging from 3800-5800mm, balancing traffic flexibility and loading capacity. It can adapt to different scales of garbage collection scenarios and efficiently complete centralized cleaning tasks. Equipped with a high-performance hydraulic system, the core components are selected from well-known domestic brands. It is equipped with a Zhongmei large-diameter five in one manual and pneumatic multi way valve, a joint venture iron shell hydraulic gear pump, a Jiashan power take-off, and a constant force oil cylinder (with a two-year warranty). The operation is stable and reliable, and the hydraulic circuit pressure is sufficient. It adopts bidirectional compression technology, combined with an external sliding plate cylinder structure design and graphene nylon slider, which can efficiently compress garbage with excellent compression ratio. It can significantly reduce the volume of garbage, maximize the use of storage space in the box, effectively improve single transfer volume, reduce transportation frequency, and reduce operating costs. The carriage is made of high-strength wear-resistant steel plates, combined with robot automated welding technology, with a sturdy structure, corrosion resistance, and impact resistance. It can withstand long-term high-pressure compression operations, is not easily deformed, and is suitable for long-term high-intensity environmental sanitation operations. Adopting a fully sealed carriage design, the joint surface between the carriage and the filler is equipped with tight sealing strips and hydraulic locking devices, effectively preventing garbage scattering, odor diffusion, and leachate leakage, completely solving the problem of secondary pollution during garbage transportation, and meeting the requirements of modern environmental sanitation and environmental protection operations. The vehicle is equipped with a rear sewage tank as standard, which adopts a Zhonglian style double row sewage outlet. It can collect the leachate generated during the compression and dumping process of garbage, and discharge it synchronously during unloading to avoid sewage pollution of the road surface and surrounding environment. At the same time, side sewage tanks can be installed according to demand to further improve the environmental protection effect and comply with relevant national environmental regulations.
